Product OverviewThe Colorlight A500 is an all-in-one LED display player/processor that combines both synchronous and asynchronous control in a single compact unit. It is designed for large-scale LED video wall deployments that need high pixel capacity, flexible network connectivity (LAN, 4G, 5G, or Wi-Fi), and reliable 24/7 operation, making it suitable for advertising screens, rental displays, and fixed installations alike.
Product Specifications
• Storage: 4G DDR + 64GB EMMC
• Loading Capacity: Up to 5.20 million pixels, with maximum width of 7680 pixels or maximum height of 4096 pixels
• Supported Receiving Cards: All series of Colorlight receiving cards
• Operating System: Android 13
Video & Audio Support
• Video Decoding: Up to 8K@60FPS, supporting HEVC, H.264, H263, AV1, VP9, AVS2, MVC, MPEG-4, MPEG-1/2, Google VP8, VC-1, and Motion JPEG
• Audio Formats: AAC-LC, HE-AAC, HE-AAC v2, MP3, and Linear PCM
Connectivity & Interfaces
• Network: Accesses the network through LAN, 4G, 5G, or Wi-Fi
• Front Panel: LCD status screen, function knob, function buttons (ESC/Bright/Black/ASYNC/HDMI1/HDMI2/HDMI3/PRESET), power switch, USB 2.0, SIM card slot
• Rear Panel: Power input (AC100-240V, fused), RS232 (RJ11, central controller), RS485 (sensor/M2), Gigabit LAN, USB-A 3.0, USB Type-C (display params/program publish), HDMI 1 in (3840x2160@60Hz), HDMI 2/3 in (3840x2160@30Hz), HDMI 2.0 out (3840x2160@60Hz), SPDIF out, 3.5mm audio out, 8x Gigabit Ethernet output ports (single port up to 650,000 pixels, total 5.2 million pixels), and grounding terminal
Environmental & Power
• Power Input: AC100-240V
• Rated Power: 50W
• Operating Temperature: -20C to 70C (-4F to 158F)
• Operating Humidity: 0%RH-95%RH, non-condensing
Dimensions
• Unboxed Dimensions (W x H x D): 482.6mm x 51.0mm x 360.92mm (excluding antenna and rubber feet)
Manufacturer: Colorlight
