Colorlight A30 Player

Product Overview

The Colorlight A30 is a new-generation cloud networking LED player supporting ColorlightCloud, WiFi and wired network connectivity. It deploys rapidly and enables intelligent cloud management across multiple screens, multiple businesses and multiple regions from a single platform. The A30 is suited to indoor and outdoor fixed installations that require centralised publishing, scheduling and monitoring, and is widely used for lamp post screens, store display screens, advertisement players, mirror screens and vehicle screens.

Loading Capacity and Performance

• Loading capacity: up to 650000 pixels
• Maximum resolution: 2560 pixels in width or 2560 pixels in height
• Hardware performance: HD hard decoding playback
• Video decoding: H.265 (HEVC) and H.264 hard decoding
• Operating system: Android
• Storage: 32GB total, 25GB available
• Receiving cards supported: all series of Colorlight receiving cards

Playback and Content

• Program pages: up to 32 pages of playback
• Program schedule: multi-program sequential playback with program timing setting
• Multi-window display: a single HD video window, or up to 2 SD video windows
• Additional windows: picture/text, scrolling text, scrolling picture, LOGO, date/time/week and weather forecast
• Window overlaying: arbitrary overlapping with transparent and opaque effects
• Media scaling: video and picture scaling supported
• USB plug and play: content and program updating from a USB drive
• Synchronised playback across multiple displays
• Command and program schedules supported

Supported File Formats

• Video: HEVC (H.265), H.264, MPEG-4 Part 2, Motion JPEG
• Audio: AAC-LC, HE-AAC, HE-AAC v2, MP3, Linear PCM
• Image: BMP, JPG, PNG, GIF
• Text: TXT, RTF, Word, PPT, Excel (used in conjunction with PlayerMaster)
• Text display: single-line, multi-line, static and scrolling text

Networking and Control

• WiFi: 2.4G band, WiFi hotspot mode and WiFi client mode
• LAN: wired network with DHCP and static IP modes
• 4G communication: supported (optional)
• GPS positioning: optional
• Control platforms: LED Assistant for mobile phone and tablet, PlayerMaster for PC, ColorlightCloud for cloud management

Interfaces

• Type-C: sets display parameters and publishes programs
• USB: connects a USB flash drive or USB camera
• LAN: Ethernet port for wired network
• DISPLAY: Ethernet output to the receiving cards of the display
• AUDIO: 3.5mm audio jack for Hi-Fi stereo output
• SENSOR: RJ11 port for automatic brightness adjustment or monitoring of ambient light, smoke, temperature, humidity and air quality
• WIFI ANT: WiFi antenna connector, 2.4G band
• Reset: press and hold the reset pin for 8 seconds to restore factory settings
• DC IN: DC 3.5V to 12V power input

Electrical and Environmental

• Power input: DC 3.5-12V
• Rated power: 10W
• Operating temperature: -30°C to 75°C (-22°F to 167°F)
• Operating humidity: 0%RH to 95%RH, non-condensing
• Dimensions (L x W x H): 106.8mm x 98.4mm x 14.7mm
• Real-time clock: RTC display and management
• Manufacturer: Colorlight Cloud Tech Ltd.
