Control SystemsVideo Processors Colorlight X12 Video Processor

Colorlight X12 Video Processor

Colorlight X12 video processor - a high-capacity full-color LED display controller supporting up to 7,800,000 pixels (max 8192x4096), with 3x HDMI 1.4 and 1x DVI inputs, 12x Gigabit Ethernet outputs, and AC 100-240V power input for large-scale rental and fixed-installation LED video walls.
₹124,999.00
Product Details
Product Overview
The Colorlight X12 is a professional full-color LED video processor and controller supporting large-scale LED display walls, with high pixel loading capacity, multi-source video input, and extensive Ethernet output for rental, fixed-installation, and broadcast applications.
Key Features
Loading capacity: 7,800,000 pixels | max 8192x4096
Multiple simultaneous HDMI/DVI video inputs with seamless switching
12x Gigabit Ethernet outputs for large cabinet counts
Professional-grade construction for rental and touring use
Input & Output Interfaces
Video Inputs: 3x HDMI 1.4 In, 1x DVI In
Ethernet Outputs: 12x Gigabit Ethernet Out
Control: RS232, USB 2.0 In, USB 2.0 Out
Audio: Audio In, Audio Out
Front Panel Controls
LCD display, Knob, Function Keys, Video Signal Selection Keys, Power Switch
Physical & Environmental
Dimensions (unboxed): 482.6 x 88.0 x 369.2 mm | Net Weight: 4.6 kg
Power Input: AC 100-240V | Rated Power: 30W
Operating Temperature: -30C to 60C (-22F to 140F) | Humidity: 0-80% non-condensing
Specifications
Technical Specifications
  • Loading Capacity
    :
    7800000 pixels | max 8192x4096
  • Supported Receiver
    :
    All Colorlight receivers
  • Front Panel Ports
    :
    LCD / Knob / Function Keys / Video Signal Selection Keys / Power Switch
  • Power Input
    :
    AC 100-240V
  • Rated Power
    :
    30W
  • Operating Temperature
    :
    -30°C to 60°C (-22°F to 140°F)
  • Operating Humidity
    :
    0-80% non-condensing
  • Dimensions (Unboxed)
    :
    482.6 × 88.0 × 369.2 mm
  • Net Weight
    :
    4.6 kg
  • Rear Panel Ports
    :
    3x HDMI1.4 In / 1x DVI In / 12x Gigabit Ethernet Out / RS232 / USB2.0 In / USB2.0 Out / Audio In / Audio Out / AC Power In
