Colorlight X7 Video Processor
Colorlight X7 LED video controller — a professional 1U control system and video processor with 2× DVI, 1× HDMI 1.4 and 1× 3G-SDI inputs, seamless source switching with broadcast-quality scaling, up to 3 layers, and 8 Gigabit Ethernet outputs loading up to 5.2 million pixels (max 8192 wide or 4096 high).
₹60,100.00
Share :
Product Details
Product Overview
The Colorlight X7 is a professional control system and video processing unit designed for LED engineering applications. It combines high-definition digital inputs (DVI, HDMI, SDI) with seamless switching, broadcast-quality scaling and multi-picture display, and drives large LED walls through 8 Gigabit Ethernet outputs with port or controller redundancy.
Video Inputs & Signal Formats
• Inputs: 2× DVI | 1× HDMI 1.4 | 1× SDI (3G-SDI with de-interlacing)
• Max input resolution: 1920×1200@60Hz
• SDI formats: 1920×1080i/p and 1280×720p
• Color: YCbCr 4:2:2 / 4:4:4 and RGB 4:4:4, 8-bit
• HDCP supported
Output & Load Capacity
• 8× Gigabit Ethernet (RJ45) outputs
• Loading capacity up to 5.2 million pixels
• Max 8192 pixels wide or 4096 pixels high
• Ethernet port redundancy or controller redundancy
Processing & Control
• User-definable video source switching and scaling
• Up to 3 layers with custom position and size
• Brightness and color temperature adjustment
• Better Gray Level at Low Brightness for complete grayscale at low brightness
• Independent audio input and HDMI audio decoding (3.5mm in/out)
• RS232 protocol (RJ11) | USB in/out for PC debugging and cascading
Physical & Electrical
• 1U chassis: 482.6 × 44.0 × 306.2 mm | Net weight: 3.10 kg
• Boxed: 525.0 × 95.0 × 355.0 mm | Total weight: 4.26 kg
• Power input: AC100-240V, 1.0A, 50/60Hz
• Rated power: 30W (with all cards installed)
Environmental & Certification
• Operating: -20°C to 60°C | 0-80% RH non-condensing
• Storage: -30°C to 80°C | 0-90% RH non-condensing
• Certification: CCC, CE, FCC, IC, EAC, UKCA
• Manufacturer: Colorlight Cloud Tech Ltd.
Specifications
Technical Specifications
- Signal Sources (Input):2×DVI, 1×HDMI1.4, 1×SDI
- Input Resolution:max 1920×1200@60Hz
- Output Loading Capacity:5.2 million pixels
- Max Width / Height:8192px width / 4096px height
- Ethernet Output Ports:8× Gigabit Ethernet
- Audio I/O:1×3.5mm in, 1×3.5mm out (HDMI audio decoding)
- Control Interface:RS232, USB IN/OUT (cascading)
- Chassis Size (Unboxed):482.6 × 44.0 × 306.2 mm
- Chassis Size (Boxed):525.0 × 95.0 × 355.0 mm
- Net Weight:3.10 kg
- Gross Weight:4.26 kg
- Power Input:AC100-240V, 50/60Hz
- Rated Power:30W (with all cards installed)
- Operating Temperature:-20°C to 60°C (-4°F to 140°F)
- Operating Humidity:0%RH-80%RH, non-condensing
- Certification:CCC, CE, FCC, IC, EAC, UKCA
