A 700 mm flat ribbon cable with the 16-pin HUB75E pinout, fitted with 2.54 mm IDC connectors at both ends in the same orientation. The ribbon itself is 1.27 mm pitch copper. In a cabinet it runs from the receiving card to the head module of a row that sits two or three rows away from the card, so the 700 mm length covers that span without slack bunched behind the modules. Cut length is held to a tolerance of 5 mm.
Key details
- 16-pin HUB75E data cable, 700 mm long, tolerance 5 mm
- 1.27 mm ribbon pitch, copper conductor
- 2.54 mm IDC connector at both ends, same orientation
- Receiving card to module row two or three rows away
- Category: LED display accessories
For cabinet assemblers and service engineers wiring HUB75E modules to a receiving card. Shorter rows nearer the card take the 400 mm version and rows four or five away take the 1100 mm version, so a cabinet is wired with a mix of lengths and no excess ribbon. Ex-stock Mumbai, delivered across India by Lumina Display Systems.
