A 700 mm flat ribbon cable with the 26-pin HUB320 pinout, fitted with 2.54 mm IDC connectors at both ends in the same orientation on a 1.27 mm pitch copper ribbon. It is for the E320 receiving card line only, since HUB320 is a 26-pin interface and will not mate with a HUB75E header. The 700 mm length is the middle size in the series, cut for the run from the card to the head module of a row two or three rows away.
Key details
- 26-pin HUB320 data cable, 700 mm long
- 1.27 mm ribbon pitch, copper conductor
- 2.54 mm IDC connector at both ends, same orientation
- For the E320 receiving card line only
- Card to module row two or three rows away
For integrators and cabinet assemblers wiring E320-series receiving cards to HUB320 modules. Use the 400 mm cable for the row next to the card and the 1100 mm cable for rows four or five away. Ex-stock Mumbai, delivered across India by Lumina Display Systems.
