Huidu HD-C08L Full-Color Asynchronous LED Control Card (196K px)
Huidu HD-C08L asynchronous LED control card - a computer-free multimedia player card that drives up to 196000 pixels (max 2048 wide or 1024 high) through 8 HUB75E ports, with Wi-Fi app control, 4GB storage, two 1080P video windows, an onboard power relay and -40°C to 80°C operation for small and medium full-colour LED screens.
Non-returnable
Out of stock
₹7,250.00
Share :
Product Details
Product Overview
The Huidu HD-C08L is a new-generation LED multimedia playback card with 8 HUB75E interfaces that drives the screen directly, with no computer needed as a video source. It plays video, pictures, GIF animations, text, WPS documents, tables, clocks and timers at a 60Hz frame rate, with Wi-Fi app control, XiaoHui Cloud management and remote power control for shop signs, door-head and medium full-colour LED screens.
Control Capacity
• Load capacity: 196000 pixels | Max width 2048 pixels or max height 1024 pixels
• Modules: HUB75 (B/D/E) full-colour and single-colour modules | 60Hz frame rate output
Interfaces
• Outputs: 8x HUB75E | TRS 3.5mm stereo audio
• Inputs: 1x 100M network port | 1x USB for program update and storage expansion
• Sensors: temperature sensor port | GPS port | universal sensor port (temperature, humidity, brightness, wind, noise, PM2.5, PM10, CO2)
• Control: onboard relay (AC 250V 3A / DC 30V 3A) | 3x CTRL detection inputs | RS-232 / RS-485 optional
Functions
• 2.4GHz Wi-Fi (AP and STA modes) | 4G optional for remote cloud management
• Two simultaneous 1080P video windows | 1080p@60fps hardware decoding
• Sequential, timed and inserted program playback | multi-window program layouts
• Remote power on/off via the onboard relay | voice broadcast optional
Media Formats
• Video: AVI | WMV | MPG | RM/RMVB | VOB | MP4 | FLV
• Images: BMP | GIF | JPG | JPEG | PNG | PBM | PGM | PPM
• Audio: MPEG-1 Layer III | AAC
Electrical and Environmental
• Input power: DC 5V (4.6V to 5.5V) | Max power consumption: 8W
• Processor: 1.5GHz quad-core CPU with Mali-G31 GPU | Storage: 4GB (2GB available), expandable via USB
• Operating temperature: -40°C to 80°C | Humidity: 0 to 80% RH non-condensing
• Board size: 142 x 91.21 mm | Net weight: 0.114 kg | Bare board, not waterproof
Software and Manufacturer
• Software: HDPlayer (PC) | LedArt mobile app (iOS / Android / HarmonyOS) | XiaoHui Cloud remote management | Linux 4.4
• Manufacturer: Shenzhen Huidu Technology Co. Ltd. | Supplied in India by Lumina Display Systems
Specifications
Technical Specifications
- Memory:4GB (2GB available)
- Loading Capacity:196000 pixels | max width 2048 or height 1024
- Supported Receiver:None - drives modules directly via HUB75E
- Video Format Support:AVI / WMV / MPG / RM-RMVB / VOB / MP4 / FLV
- Audio Format Support:MPEG-1 Layer III / AAC
- Connectivity:WiFi / LAN / 4G (optional) / GPS (optional)
- Power Input:DC 5V (4.6V-5.5V)
- Rated Power:8W
- Operating Temperature:-40°C to 80°C
- Operating Humidity:0-80% non-condensing
- Dimensions (Unboxed):142 x 91.21 mm
- Net Weight:0.114 kg
- Operating System:Linux 4.4
