Huidu HD-D16 Full-Color Asynchronous LED Control Card (65K px)
Huidu HD-D16 asynchronous LED control card - a compact full-colour controller for lintel, door-head, vehicle and small LED screens that drives up to 65000 pixels (max 1024 wide or 256 high) through 4 HUB75E ports, with Wi-Fi app control, 4GB storage, static to 1/64 scan support and -40°C to 80°C operation.
Non-returnable
Out of stock
₹6,300.00
Share :
Product Details
Product Overview
The Huidu HD-D16 is a compact full-colour asynchronous control card for lintel LED screens, vehicle screens and small full-colour displays, with 4 HUB75E ports on board. It has a built-in Wi-Fi module for LedArt app control, supports HDPlayer and XiaoHui Cloud management, updates programs over USB and plays video, pictures, GIF animations, text, WPS documents, tables, clocks and timers at a 60Hz frame rate.
Control Capacity
• Load capacity: 65000 pixels | Max width 1024 pixels or max height 256 pixels
• Modules: static to 1/64 scan | Grey scale 256 to 65536 | 60Hz frame rate output
Interfaces
• Outputs: 4x HUB75E
• Inputs: 1x 10/100M RJ45 network port | 1x USB 2.0 for program update and storage expansion
• Sensors: temperature sensor port | GPS port | universal sensor port
• Control: 3x CTRL detection inputs | RS-232 / RS-485 optional | external relay optional for remote power control
Functions
• Wi-Fi (AP and STA modes) | 4G optional for remote cloud management
• One video window | 720P video hardware decoding with no transcoding wait
• Neon backgrounds, animated words, clocks and count up / count down timers
• Temperature and humidity display | adaptive brightness adjustment
Media Formats
• Video: AVI | WMV | MP4 | 3GP | ASF | MPG | FLV | F4V | MKV | MOV | DAT | VOB | TRP | TS | WEBM
• Animation: SWF | FLV | GIF
• Images: BMP | JPG | JPEG | PNG
Electrical and Environmental
• Input power: DC 5V (4.6V to 5.5V) | Max power consumption: 5W
• Processor: 1.5GHz quad-core CPU with Mali-G31 GPU | Storage: 4GB (2GB available), expandable via USB
• Operating temperature: -40°C to 80°C | Humidity: 0 to 80% RH non-condensing
• Board size: 142 x 74 mm | Net weight: 0.08 kg | Bare board, not waterproof
Software and Manufacturer
• Software: HDPlayer (PC) | LedArt mobile app (iOS / Android / HarmonyOS) | XiaoHui Cloud remote management | Linux 4.4
• Manufacturer: Shenzhen Huidu Technology Co. Ltd. | Supplied in India by Lumina Display Systems
Specifications
Technical Specifications
- Memory:4GB (2GB available)
- Loading Capacity:65000 pixels | max width 1024 or height 256
- Supported Receiver:None - drives modules directly via HUB75E
- Video Format Support:AVI / WMV / MP4 / 3GP / ASF / MPG / FLV / F4V / MKV / MOV / DAT / VOB / TRP / TS / WEBM
- Connectivity:WiFi / LAN / 4G (optional) / GPS (optional)
- Power Input:DC 5V (4.6V-5.5V)
- Rated Power:5W
- Operating Temperature:-40°C to 80°C
- Operating Humidity:0-80% non-condensing
- Dimensions (Unboxed):142 x 74 mm
- Net Weight:0.08 kg
- Operating System:Linux 4.4
