Qiangli Q4 Pro - P4 Outdoor LED Module, 7680Hz

The Qiangli Q4 Pro (Item No. Q4Pro, Spec 10S-Pro-1921) is an outdoor full-color 1/10 scan LED module built for high-brightness outdoor video walls and signage, delivering up to 7680Hz refresh rate for smooth, camera-friendly imaging, with magnetic-attraction, front-maintenance cabinet mounting.

• Pixel Pitch: 4mm | Pixel Density: 62500 dots/m²

• Configuration: 1R1G1B | LED Type: SMD1921

• Module Size: 320 x 160 x 18mm | Module Weight: 0.52kg ± 0.01kg

• Resolution: 80 x 40 (3200 dots)

• Input Voltage: DC 4.5V ± 0.1V | Max Current: ≤10.34A

• Power Consumption: ≤47W | Driving Method: Constant current, 1/10 scan

• Brightness: ≥5000 cd/m² | Brightness Uniformity: >0.95

• Viewing Angle: 140°(H) ±10° / 130°(V) ±10°

• Best Viewing Distance: ≥7.2m | Operation Environment: Outdoor

• Grayscale: 14–16 bit (RGB each) | Display Color: 4398 billion

• Frame Frequency: ≥60 fps | Refresh Frequency: ≥7680Hz

• Control Mode: Computer control, point-to-point, video synchronization, real-time display

• Input Signal: DVI/VGA/HDMI/DP, composite video, S-Video, YPbPr (HDTV)

• Operating Temperature: -20°C to 40°C

• Operating Humidity: 10%–90% RH (no condensation)

• Average Failure Free Time: ≥5,000 hours

• Flatness: <1 mm/m² (horizontal & vertical)

• Protection: Over-temperature / overload / power-down / image compensation / over-current / over-voltage / lightning protection (optional)

• Cabinet Size: 960 x 960 x 104.5mm (module + cabinet) / 960 x 960 x 169.5mm (with connecting piece)

• Cabinet Pixels: 240 x 240 (57,600 dots) | Cabinet Area: 0.9216m²

• Cabinet Weight: 29.7kg ± 0.5kg

• Cabinet Max Power: ≤838W | Average Power (1/3 max): ≤279W

• Driving: Constant current, 1/10 scan, magnetic-attraction & front maintenance

Manufacturer: Xiamen Qiangli Jucai Opto-Electronic Technology Co., Ltd.
